Dump Trailers

70SR | 10SR | 10LX | 12LX | 14LX | 14OD | 14OD-GN | 21GX | 25DU


70SR Tandem Axle Single Ram Dump Bed Trailers

70SR
*Model #: 70SR

Standard Sizes:

  • 60″ x 10′
  • 72″ x 10′

Carrying Capacity:

5,100# Approximate Payload – Box Capacity of 3 Cubic Yards

Features:

  • 2-5/16″ Stamped A-Frame Coupler
  • 15″ Tires (5 bolt)
  • 20″ – 16 Gauge Sides with Formed Channel Supports
  • Enclosed Pump and Battery Box
  • 16 Gauge Floor
  • Lockable Control Unit
  • Single Cylinder Lift
  • J-Hooks on All Sides
  • Tarp Brackets
  • 1 Piece 2-Way Style Rear Gate

Trailer Specs: Click Here




10SR Low Profile Tandem Axle Dump Trailers

10SR
* Model #: 10SR

Standard Sizes:

  • 83″ x 12′

Carrying Capacity:

6,600# Approximate Payload – Box Capacity of 6.2 Cubic Yards

Features:

  • 2-5/15″ Adjustable Forged Coupler
  • 16″ Tires (6 bolt)
  • 24″ 12 Gauge Sides
  • Enclosed Pump and Battery Box
  • 10 Gauge Floor
  • Modular Sealed Wiring Harness
  • Self Contained Electric/Hydraulic Single Cylinder Lift
  • 1/2″ Tie Rail on All Four Sides
  • Stake Pockets on Sides and Front
  • Trap Brackets
  • Combo Gate
  • Only Available in Black

Trailer Specs: Click Here




10LX Tandem Axle Low Profile Extra Wide Dumps

10LX
* Model #: 10LX

Standard Sizes:

  • 83″ x 10′
  • 83″ x 12′

Carrying Capacity:

6,270# Approximate Payload – Box Capacity of 6.2 Cubic Yards

Features:

  • 2-5/16″ Adjustable Forged Coupler
  • 16″ Tires (8 bolt)
  • 24″ 12 Gauge Sides with Formed Channel Supports
  • Enclosed Pump & Battery Box
  • 10 Gauge Floor
  • Lockable Control Unit
  • Self Contained Electric/Hydraulic Scissor Lift
  • Trap Brackets
  • 1/2″ Tie Rail on All Sides
  • Stake Pockets (sides & front)
  • Four 5/8″ D-Rings Inside Bed
  • Double Rear Gates with Cam Latch

Trailer Specs: Click Here




12LX Tandem Axle Low Profile Extra Wide Dump Trailers

12lx
* Model #: 12LX

Standard Sizes:

  • 83″ x 12′

Carrying Capacity:

8,300# Approximate Payload – Box Capacity of 6.2 Cubic Yards

Features:

  • 2-5/16″ Adjustable Forged Coupler
  • 16″ Tires (8 bolt)
  • 24″ – 12 Gauge Sides with Formed Channel Supports
  • Enclosed Pump & Battery Box
  • 10 Gauge Floor
  • Lockable Control Unit
  • Self Contained Electric/Hydraulic Scissor Lift
  • Tarp Brackets
  • 1/2″ Tie Rail on All Sides
  • Stake Pockets (sides & front)
  • Four 5/8″ D-Rings Inside Bed
  • Double Rear Gates with Cam Latch

Trailer Specs: Click Here




14LX Tandem Axle Low Profile Extra Wide Bumper Pull Dump Trailers

14LX
* Model #: 14LX

Standard Sizes:

  • 83″ X 14′ or 16′

Carrying Capacity:

9,500# to 9,800# Approximate Payload – Box Capacity Ranges from 7.2 Cubic Yards to 8.3 Cubic Yards

Features:

  • 2-5/16″ Adjustable Forged Coupler
  • 16″ Tires (8 bolt)
  • 24″ High, 12 Gauge Sides with Formed Channel Supports
  • Enclosed Pump & Battery Box
  • 10 Gauge Floor
  • Lockable Control Unit
  • Fully Self Contained Electric/Hydraulic Scissor Lift
  • 1/2″ Tie Rail on All Sides
  • Stake Pockets (sides & front)
  • Trap Brackets
  • Four 5/8″ D-Rings Inside Bed
  • Double Rear Gates with Cam Latch

Trailer Specs: Click Here




14GX Tandem Axle Low Profile Extra Wide Gooseneck Dump Trailers

14GX
* Model #: 14GX

Standard Sizes:

  • 83″ x 14′ or 16′

Carrying Capacity:

8,700# to 9,000# Approximate Payload – Box Capacity Ranges from 7.2 Cubic Yards to 8.3 Cubic Yards

Features:

  • 2-5/16″ Adjustable Pipe Coupler
  • 16″ Tires (8 bolt)
  • 24″ – 12 Gauge Sides with Formed Channel Supports
  • Enclosed Pump & Battery Box
  • 10 Gauge Floor
  • Lockable Control Unit
  • Fully Self Contained Electric/Hydraulic Scissor Lift
  • 1/2″ Tie Rail on All Sides
  • Stake Pockets (sides & front)
  • Trap Brackets
  • Four 5/8″ D-Rings Inside Bed
  • Double Rear Gates with Cam Latch

Trailer Specs: Click Here




14OD Tandem Over the Axle Bumper Pull Dump Trailers

14OD
* Model #: 14OD

Standard Sizes:

  • 96″ x 14′

Carrying Capacity:

9,800# Approximate Payload – Box Capacity of 6.2 Cubic Yards

Features:

  • 2-5/16″ Adjustable Forged Coupler
  • 16″ Tires (8 bolt)
  • 18″ – 10 Gauge Fold Down Sides
  • Enclosed Pump & Battery Box
  • 10 Gauge Floor
  • Lockable Control Unit
  • Fully Self Contained Electric/Hydraulic Scissor Lift
  • Trap Brackets
  • Four 5/8″ D-Rings Inside Bed
  • Combo Gate
  • 7′ Slide in Ramps

Trailer Specs: Click Here




14OD-GN Tandem Over the Axle Gooseneck Dump Trailers14OD-GN

* Model #: 14OD-GN

Standard Sizes:

  • 96″ x 14′

Carrying Capacity:

8,800# Approximate Payload – Box Capacity of 6.2 Cubic Yards

Features:

  • 2-5/16″ Adjustable Pipe Coupler
  • 16″ Tires (8 bolt)
  • 18″ – 10 Gauge Fold Down Sides
  • Enclosed Pump & Battery Box
  • 10 Gauge Floor
  • Lockable Control Unit
  • Fully Self Contained Electric/Hydraulic Scissor Lift
  • Trap Brackets
  • Four 5/8″ D-Rings Inside Bed
  • Combo Gate
  • 7′ Slide in Ramps

Trailer Specs: Click Here




21GX21GX Triple Axle Low Profile Extra Wide Dump Trailers

* Model #: 21GX

Standard Sizes:

  • 83″ x 16′

Carrying Capacity:

14,800# Approximate Payload – Box Capacity of 8.3 Cubic Yards

Features:

  • 2-5/16″ Adjustable Pipe Coupler
  • 16″ Tires (8 bolt)
  • 24″ – 12 Gauge Sides with Formed Channel Supports
  • Enclosed Pump & Battery Box
  • 10 Gauge Floor
  • Lockable Control Unit
  • Fully Self Contained Electric/Hydraulic Scissor Lift
  • Trap Brackets
  • Four 5/8″ D-Rings Inside Bed
  • Double Rear Doors

Trailer Specs: Click Here




25DU Tandem Dual Gooseneck Dump

25DU* Model #: 25DU

Standard Sizes:

  • 92″ x 18′
  • 92″ x 20′

Carrying Capacity:

17,340# to 17,800# Approximate Payload – Box Capacity Ranges from 21.98 Cubic Yards to 23.70 Cubic Yards

Features:

  • 30K 2 5/16″ Adjustable Crank Type Coupler
  • 3/8″ Grade 70 w/safety latch hooks
  • 2- 12K Bolt-On Drop Leg Jacks
  • 16″ Tires – 8 Bolt
  • Lockable pump & battery box between gooseneck uprights
  • 48″ Sides w/formed channel supports
  • J-Hooks for tie down
  • Heavy Duty 10 gauge floor
  • 4 5/8″ D-rings inside bed
  • Self contained electric hydraulic scissor lift
  • 45 Degree dump angle
  • Rubber mounted sealed LED lighting & modular sealed wiring harness
  • Complete break-a-way system w/charge line
  • Double rear gates w/cam latch
  • Removable header across rear

Trailer Specs: Click Here



Features Spotlight

Big Tex Dump Trailers

Big Tex strives to ensure the accuracy of information presented on this site. Due to the high volume of trailers manufactured by Big Tex each year, and our dedication to always find ways to improve the design and performance of our trailers, there may be some variation in the information presented here and the actual trailer specifications. Specifications and Options subject to change without notice.
* NOTES: LED Lighting is now being installed on all gooseneck trailers as their standard lighting package as of 8/7/2012
